5014i-IK + STM-S

Low Voltage LED Sign Light on a Stanchion Mount

The 5014i-IK + STM-S is a Sign Light fixture integrating factory-fitted LEDs for high-performance illumination with reflector optics and integral drivers, all within a robust A360 die-cast aluminum body. Despite its small size, the 5014i is capable of delivering up to 400 lumens, with wattages ranging from 1.5W to 3.5W, and offers a choice of color temperatures between 3000°K and 5000°K. Its door is designed to shed water from the lens surface, and a durable polyester powder coat finish is available in 18 standard colors. The fixture's fully adjustable Infinity Knuckle is mounted on a Stanchion Mount, extending the fixture off a surface for a variety of lighting applications.
Specification Sheet

Resources

CCT

  • 3000K
  • 4000K
  • 5000K

CRI

  • 80

Color / Finish

  • Architectural Brick
  • Architectural Bronze
  • Black
  • Dark Bronze
  • Glossy Gray
  • Granite
  • Graphite Metallic
  • Hunter Green
  • Light Bronze
  • Mocha
  • Olde Finish
  • Pewter
  • Rust
  • Special Bronze
  • Verde
  • Weathered Bronze
  • Weathered Iron
  • White

Lamp Source

  • LED

Listings

  • cULus

Lumens

  • 180
  • 400

Materials

  • Aluminum

Mounting

  • STM

Ratings & Compliance

  • Build America Buy America (BABA)
  • Buy American Act (BAA)

Static LED Color

  • White

Voltage

  • 12 V

Watts

  • 1.5
  • 2.5
  • 3.5
