1043Y + STM-S
LED Sign Light on a Stanchion Mount
The 1043Y + STM-S is a Sign Light fixture with integrated high-density array (HDA) LED. It's equipped with high-performance reflector optics, integral drivers, and is crafted from die-cast aluminum. The 1043Y is capable of delivering up to 1200 lumens, with wattages ranging from 4.5W to 20W. It supports both 0-10V and Phase Cut dimming options. Its door is specifically designed to shed water from the lens surface. A durable polyester powder coat finish is applied to the 1043Y, available in 18 standard colors. Aim precision is provided by an aluminum yoke strap on a Stanchion Mount, suitable for a variety of lighting applications.
Resources
1043
Shape
- Round
Beam Angle
- 16
- 19
- 30
- 45
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 80 CRI
Color / Finish
- Architectural Brick
- Architectural Bronze
- Black
- Dark Bronze
- Glossy Gray
- Granite
- Graphite Metallic
- Hunter Green
- Light Bronze
- Mocha
- Olde Finish
- Pewter
- Rust
- Special Bronze
- Verde
- Weathered Bronze
- Weathered Iron
- White
Lamp Source
- LED
Listings
- cULus
Lumens
- 135 Lm
- 321 Lm
- 332 Lm
- 361 Lm
- 364 Lm
- 487 Lm
- 542 Lm
- 566 Lm
- 687 Lm
- 711 Lm
- 738 Lm
- 957 Lm
- 1035 Lm
- 1052 Lm
- 1188 Lm
- 1212 Lm
Materials
- Aluminum
Mounting
- STM
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- IP66
Static LED Color
- White
Voltage
- 120-277 V
Watts
- 5 w
- 7.5 w
- 10 w
- 16 w
- 17 w
- 19 w
Dimming Protocol
- 0-10 V
- ELV (Trailing Edge)
- Phase-Cut
- Tri-Dimming
- Triac (Leading Edge)
