RK94
RK94 - LED Retrofit In-Grade
The RK94 Retrofit Kit is an innovative solution for seamlessly transitioning existing Hydrel® single- or double-lens M9400 Series fixtures to the advanced, energy-efficient Vista LED technology found in the 1185 series. This retrofit kit is designed for ease of installation, eliminating the need to disrupt concrete or hardscapes, thereby saving significant time and effort in commercial settings such as hospitality or theme parks. The RK94 maintains all the high-performance features of the 1185, including Chip-On-Board (COB) LED technology, precision optics, and various light distributions with controlled cutoff. It offers more than 1700 delivered lumens in color temperatures from 2700°K to 5000°K and is IP68 rated. The RK94 Retrofit Kit not only replaces outdated halogen lighting but also enhances it with greater longevity and reduced energy consumption.
Resources
Photometry
View All
(43)
Shape
- Round
Adjustability
- Rotatable Optics
- Tilt Optics
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 80 CRI
Color / Finish
- Architectural Brick
- Black
- Dark Bronze
- Glossy Gray
- Granite
- Hunter Green
- Light Bronze
- Mocha
- Olde Finish
- Pewter
- Rust
- Special Bronze
- Stainless Steel
- Verde
- Weathered Bronze
- Weathered Iron
- White
Distribution
- Medium Flood
- Narrow Spot
- Spot
- Very Narrow Spot
- Wide Flood
Lamp Source
- LED
Listings
- ETL
Lumens
- 917 Lm
- 981 Lm
- 997 Lm
- 1141 Lm
- 1317 Lm
- 1407 Lm
- 1431 Lm
- 1625 Lm
- 1738 Lm
- 1766 Lm
Materials
- Aluminum
Ratings & Compliance
- Build America Buy America Act (BABAA)
- Buy American Act (BAA)
- IP68
Static LED Color
- White
Voltage
- 120-277 V
Watts
- 14.3 w
- 14.5 w
- 15 w
- 20.6 w
- 20.8 w
- 25.4 w
- 25.5 w
- 25.7 w
- 26 w
Diameter
- 8 In.
Dimming Protocol
- 0-10 V
- ELV
- Phase-Cut
- Triac
