1050MM

1050MM — 7" Linear LED Floodlight, Mullion Mount

The 1050MM is a 7-inch Linear LED Floodlight designed for mounting to horizontal extruded aluminum or steel mullion dividing bars between windows, or directly to door frames. The Mullion Mount bracket provides ±15° field-adjustable tilt for precise beam aiming. Delivering up to 1,000 lumens, the 1050MM is available in six distribution options to suit a range of façade and flood lighting applications. Dimming is available via 0-10V or Phase Cut drivers, and color temperature is offered from 2700K to 5000K.
Specification Sheet

Resources

Shape

  • Linear
  • Linear

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K

CRI

  • 80

Color / Finish

  • Architectural Brick
  • Architectural Bronze
  • Black
  • Dark Bronze
  • Glossy Gray
  • Granite
  • Graphite Metallic
  • Hunter Green
  • Light Bronze
  • Mocha
  • Olde Finish
  • Pewter
  • Rust
  • Special Bronze
  • Verde
  • Weathered Bronze
  • Weathered Iron
  • White

Distribution

  • Asymmetric
  • Medium Flood
  • Narrow
  • Wall Grazer
  • Wall Wash
  • Wide Flood

Lamp Source

  • LED

Length

  • 7

Listings

  • cULus

Lumens

  • 347
  • 386
  • 397
  • 439
  • 441
  • 464
  • 741
  • 823
  • 847
  • 937
  • 943
  • 990

Materials

  • Aluminum

Mounting

  • Surface
  • Surface
  • Wall
  • Wall
  • Wall

Ratings & Compliance

  • Build America Buy America (BABA)
  • Buy American Act (BAA)
  • IP66

Static LED Color

  • White

Voltage

  • 120-277 V

Watts

  • 5
  • 10

Accessories

  • Internal Glare Shield
  • Polycarbonate Lens

Dimming Protocol

  • 0-10 V
  • ELV
  • Phase-Cut
  • Triac
