1185SE
1185SE - LED Semi-Recessed In-Grade
The 1185SE COB In-Grade Fixture expands upon the versatility of the standard 1185 model, featuring its robust integrated Chip-On-Board (COB) LED technology and precision optics, but uniquely housed within a 12-inch heavy-walled exterior sleeve. This elevation makes it perfectly suited for in-grade applications requiring heightened visibility above plants, bushes, or tree lighting. The SE Series combines the high-performance light distribution of the 1185 with the added benefit of adjustable height, allowing for dynamic and adaptable lighting solutions. This fixture retains the characteristics of the 1185, such as the magnetic hot aiming system for internal tilt optics adjustment and the ventilated flow-through design for optimal cooling. Delivering more than 1700 delivered lumens in various color temperatures from 2700°K to 5000°K, the 1185SE is IP68 rated, ensuring durability and resistance against environmental elements.
Resources
Photometry
View All
(43)
Shape
- Round
Adjustability
- Rotatable Optics
- Tilt Optics
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 80 CRI
Color / Finish
- Black
- Dark Bronze
- Glossy Gray
- Granite
- Hunter Green
- Light Bronze
- Mocha
- Olde Finish
- Pewter
- Rust
- Special Bronze
- Stainless Steel
- Verde
- White
Distribution
- Medium Flood
- Narrow Spot
- Spot
- Very Narrow Spot
- Wide Flood
Lamp Source
- LED
Listings
- ETL
Lumens
- 917 Lm
- 981 Lm
- 997 Lm
- 1141 Lm
- 1317 Lm
- 1407 Lm
- 1431 Lm
- 1625 Lm
- 1738 Lm
- 1766 Lm
Materials
- Aluminum
Ratings & Compliance
- Build America Buy America Act (BABAA)
- Buy American Act (BAA)
- IP68
Static LED Color
- White
Voltage
- 120-277 V
Watts
- 14.3 w
- 14.5 w
- 15 w
- 20.6 w
- 20.8 w
- 25.4 w
- 25.5 w
- 25.7 w
- 26 w
Diameter
- 8 In.
Dimming Protocol
- 0-10 V
- ELV
- Phase-Cut
- Triac
